Nominal Voltage |
48 V |
|
Nominal Capacity |
30 Ah |
|
Energy |
1.54 kWh (approx.) |
|
Configuration |
15S5P LFP pack (3.2 V cells) |
|
Standard Charge Voltage |
52.6 V (CC/CV, as per charger design) |
|
Standard Discharge Cut-off Voltage |
37.6 V (pack level, typical) |
|
Recommended Charge Current |
≤ 0.5C (≤ 15 A) |
|
Maximum Continuous Discharge Current |
50 A (customizable) |
|
Peak Discharge Current (10s) |
50 A (customizable) |
|
Cycle Life |
≥ 3000 cycles @ 80% DOD, 25°C (typical) |
|
Ingress Protection (enclosure) |
Up to IP65 (application dependent) |
|
Operating Temperature – Charge |
0°C to +55°C |
|
Operating Temperature – Discharge |
-20°C to +60°C |
|
Storage Temperature |
-10°C to +35°C (recommended) |
|
Connector Options |
Anderson type / custom as per OEM requirement |
|
Mounting |
Vehicle chassis / under-seat / rear carrier (custom bracket design possible) |
